Product Summary
The xc5vlx30-1FFG324C is an in-system programmable configuration PROM. Available in 1 to 32 Megabit (Mbit) densities, the xc5vlx30-1FFG324C provides an easy-to-use, cost-effective, and reprogrammable method for storing large Xilinx FPGA configuration bitstreams. The xc5vlx30-1FFG324C includes both the 3.3V XCFxxS PROM and the 1.8V XCFxxP PROM.
Parametrics
xc5vlx30-1FFG324C absolute maximum ratings: (1)VCCINT, Internal supply voltage relative to GND: –0.5 to +4.0V; (2)VCCO, I/O supply voltage relative to GND: –0.5 to +4.0V; (3)VCCJ, JTAG I/O supply voltage relative to GND: –0.5 to +4.0V; (4)VIN, Input voltage with respect to GND: –0.5 to +3.6V; (5)VTS, Voltage applied to High-Z output: –0.5 to +3.6V; (6)VCCO ≥ 2.5V –0.5 to +5.5 –0.5 to +3.6 V; (7)TSTG, Storage temperature (ambient): –65 to +150℃; (8)TJ, Junction temperature: +125 +125℃.
Features
xc5vlx30-1FFG324C features: (1)In-System Programmable PROMs for Configuration of Xilinx FPGAs; (2)Low-Power Advanced CMOS NOR FLASH Process; (3)Endurance of 20,000 Program/Erase Cycles; (4)Operation over Full Industrial Temperature Range (–40 to +85℃); (5)IEEE Standard 1149.1/1532 Boundary-Scan (JTAG) Support for Programming, Prototyping, and Testing; (6)JTAG Command Initiation of Standard FPGA Configuration; (7)Cascadable for Storing Longer or Multiple Bitstreams; (8)Dedicated Boundary-Scan (JTAG) I/O Power Supply (VCCJ) ; (9)I/O Pins Compatible with Voltage Levels Ranging From 1.5V to 3.3V ; (10)Design Support Using the Xilinx Alliance ISE and Foundation ISE Series Software Packages.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 XC5VLX30-1FFG324C |
|
IC FPGA VIRTEX-5 30K 324FBGA |
Data Sheet |
|
|
||||||
|
XC5VLX30-1FFG324CES |
|
IC FPGA VIRTEX-5 ES 30K 324-FBGA |
Data Sheet |
Negotiable |
|
||||||
